Description

Package Includes WIFI Dongle & Current Transformer
• Max Efficiency of 97.6%
• 2 MPPT (Maximum Power Point Tracker)
• Operating Temperature Range: -25°C to 60°C
• Cooling: Fan Cooled <30dB
• Communication with BMS: RS485; CANBUS
• Wall Mounted
• Touchscreen Interface

Battery Input Data
• Battery Type: Lead-acid or Lithium-ion
• Battery Voltage Range: 40V to 60V
• Maximum Charging Current: 240A
• Maximum Discharging Current: 240A
• Charging Curve: 3 Stages / Equalization
• Charging Strategy for Li-Ion Battery: Self-Adaptation to BMS

PV String Input Data
• Maximum DC Input Power: 15000W
• PV Input Voltage: 450V (140V ~ 1000V)
• MPPT Range: 140V ~ 800V
• Start-up Voltage: 160V
• PV Input Current: 25A+12.5A
• No. of MPPT Trackers: 2
• No. of Strings Per MPPT Tracker: 2+1

AC Output Data
• Rated AC Output and UPS Power: 12000W
• Maximum AC Power: 13200W
• Peak Off-Grid Power: 2 times of rated power, 10 S
• AC Output Rated Current: 17.4A
• Maximum AC Output Current: 19.1A
• Maximum Continuous AC Passthrough: 60A
• Output Frequency: 50Hz / 60Hz
• Output Voltage: 230VAC / 400VAC ( Three Phase )
• Grid Type: Three Phase
