Description

Battery Input Data

Battery Type: Lead-acid or Li-lon

Battery Voltage Range: 40~60V

Max. Charging Current:  290A

Max. Discharging Current: 290A

PV String Input Data

Max. DC Input Power: 20800W

Rated PV Input Voltage: 370V

AC Output Data

Rated AC Output and UPS Power: 16000W

AC Output Rated Current 69.6A

• Power Factor 0.8 leading to 0.8 lagging
• Noise (dB): <30dB
• Weight 49kg
• Size (WxHxD) 464 x 798.4 x 300mm
• Protection Degree IP65
• Installation Style: Wall Mount
