5.12Kw LBSA Lithium Ion Battery

Sale!
Month End Specials - Hurry Up!

R19,999.00

Now comes with a free wall mount included in the box.

48v 100Ah(105Ah) 5.1kWh (tested 5.2kWh usable @ 40A) LiFePO4 Lithium Iron Phosphate Wall Mount Solar UPS Battery – 10 year warranty

Cycle life:
7000 Cycles @ 100% DoD @ 0.5C @ 25°c until 70%(70AH) Capacity retention remains

10 Year Warranty(20-30 years service life)

Details:
CAN Bus Comms: Victron, Growatt, Sunsync, DEYE
Bulk + Absorption: 56v
Float : 54v
Low Voltage Cut Off: 44v
Maximum continuous Charge/Discharge For Single Unit: 100A (Recommended 50A)
Charge for Parallel units: (100A*”Units In parallel”) / 2
Discharge for Parallel units: 100A * “Units in parallel

Display Definitions:
OV – Warn: high pressure alarm
OV – Prot: over-voltage protection
UV – Warn: low pressure alarm
UV – Prot: under-voltage protection
OT-Warn?High temperature alarm
OT-Prot?Over temperature protection
UT – Warn: low temperature alarm
UT – Prot: low temperature
OC – Warn: over-current alarm
OC – Prot: over-current protection
CAPA – Warn: remaining capacity of the alarm
OFF – USE: failure alarm
SCP?Short circuit protection

The following conditions will void your warranty:
– Short circuiting the positive and negative terminals
– Water damage
– Physical or fall damage
– Leaving the battery in a discharged state for longer then 2 weeks
– Overcharging the battery
– More then 7000 Cycles used

What’s in the box
1 x LBSA 5.1Kwh LIFEPO4 battery
1 x Wall mount bracket
1 x Protective packaging
