6.2KVA Solar System – 9.2Kw Lithium 4x 550w + Installation Kit

Sale!
Month End Specials - Hurry Up!

R37,544.00
4 × 550W JA/Canadian Mono Solar Panel
R1,999.00
1 × 6.2KVA 6200W Hybrid Inverter MPPT Vito SH6.2K48
R6,300.00
1 × 9.2KW 180A 48v Lithium Ion Fivestar Battery
R19,500.00
3 × 3M Rail
R200.00
6 × Roof Hooks For Solar
R110.00
4 × End Clamps
R30.00
4 × Middle Clamps
R30.00
30 × 6mm Solar Cable P/M
R30.00
1 × complete 12Way
R1,398.00
1 × Battery Disconnector
R450.00
Category:

Description

 48V 180Ah 9.29 kWh A-Grade Wall Mount Lithium Battery

The 51.2V 180Ah A-Grade Lithium Battery is manufactured by a world-leading manufacturer  which is joined with the Haval Motor Group which we all know are extremely recognized for their vehicles, using A-Grade Battery cells. This allows superior performance, capacity, and reliability. Using state of high power A-Grade cell technology, the Lithium Battery is designed for environmentally sensitive areas and is committed to recycling.

The FIVESTAR 48V 180Ah A-Grade Lithium Battery is widely used in industrial, residential, commercial, and private applications. The maintenance-free construction and advanced design features make the Lithium Battery the definitive choice for a wide variety of markets – Like solar and renewable energy storage for electric vehicles, industrial equipment, medical equipment, telecommunications, TVs, and UPS systems.

Energy:9.29kWh
Installation Type: Wall Mounted
Battery type-Chemistry: LiFePO4
Nominal Voltage:48V
Nominal Capacity :180Ah
Energy Density:9427 KWh
Dimensions(LxWxH) :688 x 447 x 211mm
Weight (Approx.):49.5KGS
Terminal Type: M6
Terminal Torque:8.5NM
Case Material: SPCC
BMS build-in: Yes
Internal Resistance:<30mO
Efficiency – round trip:99%
Self Discharge per Month:<3%
Max parallel connectors:16Pcs
Series connections:Not Allowed
Cycle life (0.2C, 25°C@80% DOD) Discharge Temperature:6000 Cycles
Charge Temperature :20° C to 65°
Storage Temperature :0C to 50° C
Bluetooth(App) :Optional
LCD Screen: Optional
Heating Function: Optional
Voltage Window: Optional
Recommend Charge Voltage:43.2V-58.4V
Max Charge Voltage:57.6±0.20V
Recommend Charge current:58.4±0.20V
Max Discharging Voltage:43.2±0.20V
Max Continuous Discharge Current :100A
Peak Discharge Current:150A

Size:

688 x 447 x 211 mm

49.5 Kg

What’s In the Box:

  • 1 x 48V 180Ah A-Grade Lithium Battery
  • 1 x Red (Positive) Battery Cable
  • 1 x Black (Negative) Battery Cable
  • 1 x Ethernet cable
  • 1 x Manual
  • 1x Wall Mount Bracket
  • 1x Warranty Card
  • Installation Kit





VITO Hybrid Inverter 48V 6.2KW Inverter Pure Sine Wave

 230(VAC) OUTPUT VOLTAGE OFF- GRID INVERTER FOR BACKUP POWER AND SELF CONSUMPTION APPLICATION, MAX PV INPUT VOLTAGE UP TO 450(VDC) . IT CAN ALSO WORK WITHOUT A BATTERY TO SAVE SYSTEM INVESTMENT COSTS.

Functions

  • Integrated MPPT charger controller.
  • Equalization charging function.
  • Use with Batteries or without.
  • Max PV input up to 450vDC.
  • Choose grid or solar input priority.
  • PV & Grid Power combine if PV energy is insufficient for load.
  • Flexible schedule for charging and discharging the batteries.

General Specifications

  • Module: VITO 6.2KW.
  • Battery voltage: 48vDC.
  • Battery type: Lithium/Lead-acid.

Inverter Output [AC]

  • Rated Power: 6200W.
  • AC Voltage Regulation (Battery): 230VAC ± 5%.
  • Surge Power: 10000VA for 5 sec.
  • Efficiency (Peak): 93%.
  • Waveform: Pure sine wave.
  • Transfer Time: 10ms – 20ms.

Solar Charger

  • Maximum PV Array Power: 6200W.
  • MPPT Range @ Operating Voltage: 120VDC – 430VDC.
  • Maximum PV Array Open Circuit Voltage: 450vDC.
  • Maximum Solar Charge Current: 100 A.

AC Charger

  • AC Charge Current: 80A.
  • AC Input Voltage: 230 VAC.
  • Selectable Voltage Range: 230 VAC.
  • Frequency Range : 50 Hz/60 Hz (Auto sensing).

Physical

  • Protection degree: IP20.
  • Height: 330 x 485 x 135mm.
  • Weight: 12 kg
  • Installation Kit
