Description

Hybrid Inverter 6.2 KVA 6200 Watt MPPT 48V- Conderenergy

One will be able to run lights, television, and wifi.

Compatible with mains voltage and can charge batteries.
– Auto restart while AC is recovering
– Overload and short circuit protection
– Smart battery charger design for optimized battery performance
– Cold start function

-Pure sine wave inverter
-Built-in solar charge controller
-MPPT
Operating Temperature Range: -10-50’C

PV INPUT:
Normal operating voltage:240Vdc Vmax PV:500Vdc
PV input voltage range:90-450Vdc Imax PV:27A
Full load MPPT range: 240-450Vdc Rated Power 6500W
Maximum Solar Charging Current: 120A

GRID/AC OUTPUT:
Normal Output Voltage:220/230/240Vac Feed-in Grid Voltage Range: 195-253Vac
Feed-in Grid Frequency Range: 49-51+1Hz
Normal Output Current: 27A
Power Factor Range: >0.99
Maximum Conversion Efficiency (DC/AC) :97%
Normal Operating Frequency: 50/60Hz

TWO LOAD OUTPUT POWER:
Full Load:6200W
Maximum Main load:6200W Maximum Second load:2066W Main load cut off voltage: 44Vdc Main load return voltage:54Vdc AC INPUT:
Normal operating voltage:230Vac Maximum input current:40A
Normal operating frequency:50/60Hz
Surge power:12400VA
Maximum AC charging current: 100A

What’s in the box
1 x Inverter
1 x User Manual
