8Kva Deye 10.2Kw Lithium Over 19Hours Runtime

Sale!
Month End Specials - Hurry Up!

R70,695.00

With the ultimate back up kit, loadshedding or power outages will be the thing of the past, with enough power to last you over 8hours with a single full charge, using all your lights, TVs, fridge, kettle, Wi-Fi and everything in the house except geyser and stove.

Basically you won’t feel any changes as you will be free to use all your household basics, with our Wi-Fi monitoring you can monitor your energy consumption and battery level as well as adjust settings all via your phone or tablet any where in the world.

With the hybrid functionality you can use Eskom and Solar and even Generator and set the system to efficiently generate power based on your user preferences.

All our kits comes with a complete installation kit included is.

-DB Box

-2x Circuit Breakers

-Manual Change Over Switch

-8kva Deye Hybrid Inverter

-10.2kw Dyness Lithium Ion Battery

All our products are under warranty and Guarantee.

Shipping is available but Optional

1 × 8Kva Deye Hybrid Inverter
R29,999.00
1 × Manual Change Over Switch
R199.00
4 × Battery cable P/M
R150.00
2 × Circurt Breaker
R100.00
1 × 6Way DB Board
R199.00
2 × VOLTA (STAGE 1) 5.12KWH LI-ION BATTERY
R19,999.00
Category:

Description

This is the  latest in the evolution of solar batteries , a Wall-Mounted that can Rack-Mount. What more could you ask for?

The ideal sized battery to  cycle in the evenings and reserve for load-shedding  by configuring your inverter.

Ideal to power your common appliances like your fridge freezer, TVs, lights, modem and recharge your devices for 3-4 hours during load-shedding.

The unique and stylish design includes battery connectors located on top of the battery so that you can install them on the wall, directly below your inverter. Therefore, aiding in a  neat and space-saving installation .

The 5kWh was  designed to grow with you , this battery can be paralleled to create a large battery bank.

All of these qualities make the 5kWh Battery  versatile, adaptable and perfect  for just about any application.



supply on battery option will based on stock availability



Deye 8KW Hybrid Inverter

Includes:  Wi-Fi Dongle + BMS Communication Cable

Higer yields.

  • Improve self-consumption ratio up to 80%, reducing your electricity bill.
  • DC/AC ratio up to 1.3, completely suitable for double-side PV modular.
  • Two MPPT design, Max. efficiency of 97.6%.

User-friendly.

  • LCD Touch screen and buttons, easy operation.
  • Compatible with lithium-ion battery and lead acid battery.
  • Web browser and mobile App monitoring supported.

Reliable.

  • PV lighting protection, Anti-islanding protection, Leakage current protection etc.
  • Support store energy from DG when needed, ensure the system working within 7*24H.
  • IP65 protection degree, adapt to indoor and outdoor using.
  • Automatically switch from on-grid to off-grid mode within 5ms.
  • Zero exporting function, fast reaction within 200ms in zero export mode.

Smart.

  • Programmable charging and discharging schedule.
  • Both wind turbines and solar panels can be connected as DC input power.
  • Max. 16 units can be paralleled for higher system power.
  • Retrofitting of existing solar system to energy storage system.

Battery Input Data

  • Battery Type: Lead-acid or Li-lon
  • Battery Voltage Range (V): 40-60V
  • Max. Charging Current (A): 190A
  • Max. Discharging Current (A): 190A
  • Charging curve: 3 Stages/Equalization
  • External Temperature Sensor: Optional
  • Charging Strategy for Lithium Battery: Self-adaption to BMS

PV String Input Data

  • Max. DC Input Power (W): 10400W.
  • PV input Voltage (V): 370V (100V-500V).
  • MPPT Range (V): 125-425V.
  • Start-up Voltage (V): 150V.
  • PV Input Current (A): 22A + 22A.
  • No. of MPPT Trackers: 2
  • No. of Strings Per MPPT Tracker: 2+2.

AC Output Data

  • Rated AC Output and UPS Power (W): 8000W
  • Max AC Output Power (W): 8800W
  • Peak Power(off-grid): 2 times of rated power, 10 S.
  • AC Output Rated Current(A): 33.4A/35A
  • Max.AC Output Current(A): 36.7A/38.5A.
  • Max Continuous AC Pass-through(A): 50A.
  • Output Frequency and Voltage: 50/60Hz; 120/240Vac(split phase), 208Vac(2/3 phase), 230Vac(single phase)
  • Grid Type: THD<3%(Linear load<1.5%).
  • Current Harmonic Distortion: THD<3% (Linear load<1.5%).

Efficiency

  • Max. Efficiency: 97.60%
  • Euro Efficiency: 97.00%
  • MPPT Efficiency: 99.90%

Protection

  • PV Arc Fault Detection: Integrated (Except European Type)
  • PV Input Lightning Protection: Integrated
  • Anti -islanding Protection: Integrated
  • PV String Input Reverse Polarity Protection: Integrated
  • Insulation Resistor Detection: Integrated
  • Residual Current Monitoring Unit: Integrated
  • Output over Current Protection: Integrated
  • Output Shorted Protection: Integrated
  • Output over Voltage Protection: Integrated

Certifications and Standards

  • Grid Regulation: UL1741, IEEE1547, RULE21, VDE0126, AS4777, NRS2017, G98, G99, IEC61683, IEC62116, IE61727
  • Safety Regulation: IEC62109-1, IEC62109-2
  • EMC: EN61000-6-1, EN61000-6-3, FCC 15 class B

General Data

  • Operating Temperature Range ( C ): -25—60 C , >45 C Derating
  • Cooling: Fan
  • Noise (dB): <30
  • Communication with BMS: RS485; CAN
  • Weight (kg): 32
  • Size (mm): 680 X 4200 X 233mm
  • Protection Degree: IP65
  • Installation Style: Wall-mounted
  • Warranty: 5 years
