5.5Kw Hubble Lithium Ion Battery AM2

Sale!
5.5Kw Hubble Lithium Ion Battery AM2
5.5Kw Hubble Lithium Ion Battery AM2 - Image 3
New Year - SPECIALS!

Original price was: R34,500.00.Current price is: R16,599.00.

Hubble AM-2 5.5kWh Lithium Battery

Hubble’s range of Lithium batteries communicates with a wide range of inverters through CAN bus (please see list below).

The AM Series stands for Any Mount. This gives installers more flexibility to either rack mount in a standard server cabinet or wall mounts the batteries. All AM models have full native (out the box) CAN bus integration and communication.

Features and Functions

  • Advanced BMS with current limiting function.
  • CAN Bus, fully integrates and communicates with leading Inverter brands.
  • Excellent high temperature performance.
  • High Cycle Life and Service Life.
  • RIOT integration ready for cloud monitoring.
  • 1C High Performance Lithium battery.
  • High Energy Density and conversion efficiency.
  • Complete with integrated Battery Management System.
  • Compatible with most Inverters and chargers.
  • Low self-discharge.
  • Easy wall mount or shelf rack installation.
  • Heavy duty side handles for easy handling and mounting on the wall.
  • Built in protection for over-charge, over-discharge & over-temperature.

Specifications

  • Model: Hubble AM-2.
  • Rated Capacity (5HR): 110 Ah.
  • Voltage: 51.0 V.
  • Discharge Cut-off Voltage: 42.0 V.
  • Equilized Charge Voltage: 53.6 V.
  • Max. Continuous Charging Current: 100 A.
  • Max. Continuous Discharging Current: 100 A.
  • Weight: Approx. 42 Kg.
  • Dimensions (WxDxH) mm: 375mm x 145mm x 467mm.
  • Ports: 1x CAN-bus, 2x RS-485 Battery Link ports, 1x RS232.
  • Cells: New Li-ion Prismatic cells.
  • Design Life: +/- 15 Years.
  • Cycle Life @ 1C: +/- 3000 Cycles @ 100% DOD, Above 6000 cycles @ 50% DOD.
  • Certification: CE, UN38.3, GBT31484-2015, GBT31485-2015, GBT31486-2015.
  • Outer Package Material: White bake lacquer steel case.
  • Protection: Electronic Circuit Breaker, BMS Voltage Protection, Current Limiting.
Category:

Description

Features

– Lithium pack designed to be easily wall-mounted or shelf installed in a standard rack.
– Parallel connection up to 15 packs with full communications
– +/- 3000 Cycles @ 100% DOD, Above 6000 cycles @ 50% DOD



Specifications

– Model: Hubble AM-2 REV 2
– Rated Capacity (5HR): 116 Ah
– Nominal Voltage: 48.0V
– Discharge Cutoff Voltage: 42.0V
– Equalized Charge Voltage: 53.8V
– Max. Continuous Charging Current: 105A
– Max. Continuous Discharging Current: 105A
– C Rating: 1.0C
– Weight: Approx. 42 Kg
– Display: None
– Parallel: Parallel connection up to 15 packs with full communications
– Dimensions (WxDxH) mm: 375mm x 145mm x 467mm
– Ports: 1x CAN-bus, 2x Battery Link Ports
– Cells: New Li-ion Prismatic Cells
– Cycle Life: +/- 6000 Cycles @ 50% DOD, Above 3000 cycles @ 100% DOD
– Certification: CE, UN38.3, GBT31484-2015, GBT31485-2015, GBT31486-2015
– Outer Package Material: White bake lacquer steel case
– Operating Temperature:  Charging: 0 to +55°C | Discharging: -20 to +55°C | Storage: -20 to +55°C
– Protection: Electronic Circuit Breaker, BMS Voltage Protection, Current Limiting
