11kva Solar System 28kw Lithium 18x 550w + Installation Kit

Sale!
11kva Solar System 28kw Lithium 18x 550w + Installation Kit
Clearance Sales- SPECIALS!

Original price was: R119,175.00.Current price is: R114,175.00.

SUN 51.2V 345AH 17.66KWH LITHIUM BATTERY CNY512345RN

  • Product Features
    Ultra high safe LiFePO4 battery
    Built-in BMS for multiple protection & longer lifespan
    Active balancing function and lower self-consumption
    Lightweight module design for fast installation & easy maintenance
    Parallel up to 16 modules for flexible capacity extension.
    Wide temperature range for more application scenes.

Specifications:

  • Cell Type LiFePO4
  • Nominal Voltage Nominal Capacity 51.2V
  • Nominal Energy 345Ah
  • Weight (approx.) 116kg
  • Terminal Type: Screw
  • Case Material SPCC
  • BMS Built-In Yes
  • Max.Parallel Connection Qty 16pcs
  • Series Connection No
  • Cycle Life (0.2C, 25°C@80% DOD) 6000 Cycles
  • Recommend Charge Voltage Max Charge Voltage 57.6v
  • Recommend Charge Current 50A
  • Max Continuous Charge Current 200A
  • Recommend Discharge Voltage 57.6V
  • Max Discharging Voltage 43.2V
  • Max Continuous Discharge Current 200A
  • Peak Discharge Current 250A

What’s in the box:

  • Battery
  • Battery Cables
  • Warranty Card
  • Communication cable
  • User Manual
3M Rail
12 × 3M Rail
R200.00
End Clamps
8 × End Clamps
Original price was: R35.00.Current price is: R30.00.
Middle Clamps
36 × Middle Clamps
Original price was: R35.00.Current price is: R30.00.
Roof Hooks For Solar
18 × Roof Hooks For Solar
R110.00
complete 12Way
1 × complete 12Way
R1,398.00
Battery cable P/M
4 × Battery cable P/M
R150.00
550W Canadian Mono Solar Panel
18 × 550W Canadian Mono Solar Panel
Original price was: R4,100.00.Current price is: R1,999.00.
11 KVA 11000W MPPT 160A INVERTER PURE SINE WAVE - ECCO
2 × 11 KVA 11000W MPPT 160A INVERTER PURE SINE WAVE - ECCO
Original price was: R14,500.00.Current price is: R9,300.00.
17.66KWH SUN 51.2V 345AH A-GRADE LITHIUM BATTERY
2 × 17.66KWH SUN 51.2V 345AH A-GRADE LITHIUM BATTERY
Original price was: R28,999.00.Current price is: R26,700.00.
Wifi Geyser Timer
1 × Wifi Geyser Timer
Original price was: R599.00.Current price is: R350.00.
Inverter Wi-Fi dongle
1 × Inverter Wi-Fi dongle
Original price was: R1,500.00.Current price is: R850.00.
100m 6mm Solar Cable Black
1 × 100m 6mm Solar Cable Black
Original price was: R2,999.00.Current price is: R2,295.00.
Categories: ,

Description

Hybrid Inverter 48v 11 Kva 11000w MPPT 160A Inverter Pure Sine Wave – Ecco

The main difference between PWM and MPPT charge control devices is that the MPPT devices are more efficient. MPPT charge control devices have 30 % more efficient in charge efficiency according to PWM type. Panel voltage and battery voltage should be matched in PWM systems.

Product Features

  • Built-in 2 MPPT
  • Lithium battery activation function by PV or Utility • Compatible work with LiFePO4 battery via RS485
  • Pure Sine Wave
  • Power factor 1.0
  • PV Input 500Vdc Max
  • Built-in MPPT 160A
  • Capable to work without battery
  • Detachable dust cover for harsh environment
  • Wifi remote monitoring optional
  • Support multiple output priority: SUB,SBU, SUF
  • EQ function to optimize battery performance and extend lifecycle

Specifications:

  • MODEL : HIN11000S
  • Capacity : 11KVA/11KW
  • Maximum PV Input Power : 11KW
  • Parallel Capability : NO
  • Lithium Battery Activation : YES (BY PV  OR UTILITY)
  • Lithium Battery Communication : YES(RS485)

INPUT

  • Nominal Voltage : 230VAC
  • Acceptable Voltage Range : 170-280VAC(For Personal Computer) : 90-280VAC (For Home Appliances)
  • Frequency : 50/60 Hz (Auto Sensing)

OUTPUT

  • Nominal Voltage : 220/230/240VAC
  • Surge Power : 22000VA
  • Frequency : 50/60 Hz
  • Waveform : Pure Sine Wave
  • Transfer Time : 10ms(For Computers) 20ms(For Home Appliances)
  • Peak Efficiency : 94%
  • Overload Protection : 5s @ 140% Load

BATTERY

  • Battery Voltage : 48V
  • Maximum Discharge Current : 220A
  • Floating Charge Voltage : 54VDC
  • OverCharge Protection : 63VDC
  • Charging Method : CC/CV

SOLAR CHARGER & AC CHARGER

  • Solar Charger TYPE : MPPT
  • Max.PV Array Power : 5500W*2
  • Max. PV Array Open Circuit Voltage : 500VDC
  • PV Array MPPT Voltage Range : 60VDC-500VDC
  • Max. Solar Input Current : 18A*2
  • Max. Solar Charge Current : 160A
  • Max. AC Charge Current : 120A
  • Max. Charge Current : 160A

PHYSICAL

  • Dimensions, D x W x H(mm) 540 X 415X 122
  • Net Weight (Kgs) 15KG
  • Communication Interface RS232/RS485/DRY CONTACT
  • LCD
