Description

Maximum PV input voltage up to 450 VDC

-Configurable grid or solar input priority

Integrated MPPT charge controller
· It can work with battery or without battery
· Maximun PV input voltage up to 450VDC
· Configurable grid or solar input priority

Functions

• Integrated MPPT charger controller.
• Equalization charging function.
• Max PV input up to 450vDC.
• Choose grid or solar input priority…
• PV & Grid Power combine if PV energy is insufficient for load.
• Flexible schedule for charging and discharging the batteries.
• Warranty: 2 years

General Specifications

• Module: 10.2kva Vito.
• Battery voltage: 48vDC.
• Battery type: Lithium/Lead-acid.

Inverter Output [AC]

• Rated Power: 10200W.
• AC Voltage Regulation (Battery): 230VAC ± 5%.
• Surge Power: 15000VA for 5 sec.
• Efficiency (Peak): 93%.
• Waveform: Pure sine wave.
• Transfer Time: 10ms – 20ms.

Solar Charger

• Maximum PV Array Power: 10200W.
• MPPT Range @ Operating Voltage: 120VDC – 430VDC.
• Maximum PV Array Open Circuit Voltage: 450vDC.
• Maximum Solar Charge Current: 100 A.

AC Charger

• AC Charge Current: 80A.
• AC Input Voltage: 230 VAC.
• Selectable Voltage Range: 230 VAC.
• Frequency Range : 50 Hz/60 Hz (Auto sensing).

Physical

• Protection degree: IP20.
• Height: 330 x 485 x 135mm.
• Weight: 12 kg.

+optional battery swaps without price changes- N energy 5.8kw – 5kw Rita- 5Kw Felicity- 5kw Revov.

• Installation Kit
